Now with Black Box! A new generation of Talon is here. With a F7 processor and 8S capable, Talon is the only 20X20 on the market with a STM32F722RET6 216MHz processor.  Built in Betaflight OSD, 6 UARTS, and dedicated LDOs for cleaner gyro and OSD signals makes Talon F7 the most powerful 20X20 FC on the market. One of the features Talon F4 users praised is the choice of using the 8 pin harness or direct soldering motor ports to the ESC. We’ve kept that option, while still adding more features, by letting you remove the plastic connector to reveal motor ports. Now includes 2 harness cables for direct pin to Spedix GS25A and Airbot Ori32.
Main Features
- MCU: STM32F722RET6 216MHz
- 6-Axis ICM20602 32K
- Built in Betaflight OSD
- Up to 8S (36V) direct battery power
- Buzzer pads for external buzzer
- Build in voltage monitoring resistor
- 5V 2A BEC
- 16MB Black Box
- Dedicated LDO for gyro for cleaner gyro signal
- Dedicated LDO for OSD for cleaner OSD signal
- Led strip shares 5V with 5V/2A BEC
- 6 UARTS: UART1, UART2, UART3, UART4, UART5, UART6
- Built in camera control pin with resistor and capacitor
- 4 Full UARTS with RX/TX pins
- Logical pin layout for cleanest build possible
- 8 pin 4 IN 1 ESC plug (Direct solder motor ports underneath)
- Remap able LED pad for additional motor output
- TX3 & RX3 can be used for I2C for external compass
- 5V or 3.3V selectable receiver power
- 5V, VBAT selectable VTX and CAM power
- Includes * 2 pin connector harness cables for direct pin to Spedix GS25A and Airbot Ori32, 8 grommets, M3 to M2 nut adapters, M3X5 standoffs
- pin connector (Aikon compatible)
- 8 grommets
- M3 to M2 nut adapters
- M3X5 standoffs
Betaflight Target: CLRACINGF7
