Specifications:
- Overall Dimension:Φ22.2×15mm
- Shaft Diameter:1.5mm
- Installation hole position :12×12mm，M2
- Prop: 3inch~4inch
- Bearing： 5*2*2.5
- Diameter:2mm
- Lead Wire Size：24AWG ×150mm
- Configuration:9N12P
- Magnet Wire: Class H，220℃ Enameled Wire
- Stator Diamter：16mm
- Stator Height:6mm
- Rated Voltage: 3~4S (12.6V~16.8.2V)
- Peak Current: 17.6A
- ldle Current：10V/0.5A
- Maximum Power: 409W
- Internal Resistance：164Ω
