HEE WING RC Ranger T-1 FPV Airplane 730MM wingspan EPP FPV plane-PNP PRO

T1 Ranger 730mm Assembly Guide Download:





Specifications:
Brand Name: HEE WING
Item Name: T-1 Ranger
Color: Grey, White (optional)
Version: PNP
Material: EPP / ABS+PC / carbon fiber / aluminum
Wingspan 730mm
Length: 645mm
Height: 140mm
Empty Weight: 205g
Takeoff Weight: 350g ~ 500g
Cabin Space: Length 245mm x Width 51mm x Height 48mm
Minimum Flying Speed: <20km/h
Maximum Flight Speed: >120km/h
Maximum Cruising Range: >25km
Tensile Force: >600g (measured statically with the brushless version of 3S)
Packing Size: 400mm * 230mm * 155mm
Package Weight: 880g (PNP)
New Version where the white and gray version are same strength

Features:
- Lightweight and portable, quick disassembly design, disassembly and assembly only takes one minute.
- The dual motors have strong power and the thrust-to-weight ratio is as high as 1.71.
- Excellent aerodynamic design, slower flight is more stable.
- Small wingspan, large space, easy layout of electronic equipment.
- The design of doubling the adjustable range of the center of gravity, taking into account the dual flight requirements of light load and heavy load.
- The hatch cover adopts bayonet design, the structure is more reliable.
- The new flight control system makes it easy to control the vast sky.
- Support for external cameras, which can take multiple cameras at the same time.

Check out the vtol conversions that are available for this kit - we will be stocking the conversion kits soon (vtol kits not included with this kit)
