MAIN FEATURES
ARM 32-bit Cortex MCU, frequency up to 48MHz
BL Heli_32 firmware, which is designed for superior functionality and performance
Supports regular 1-2ms pulse width input, as well as Oneshot 125, Oneshot 42, multishot. The input signal is automatically detected by the ESC upon power up
Dshot signal is supported at any rate up to at least Dshot 1200
Damped light dees regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
The ultra narrow design can effectively reduce wind resistance in flight, especially for ultra narrow arm drone
The silicone twisted-pair of the throttle signal cable effectively reduces the crosstalk caused by signal transmission, and make flight more stable
Aluminum heat sink effectively slow down the temperature rise
SPECIFICATION
Con. Current:36A Â
Burst Current (10S):42A Â
LiPo cells:3-5S
Weight:8.4g
Size:35x11x7mm
Typical Applications:170-330mm Multi
