Description


We have partnered with Chris Rosser to provide the manufacturing and shipping of his designs. This is not an Open source frame and we can not provide files or changes to this frame. With the purchase of this frame, we provide all CF and Hardware for the frame.
Please check out the designers website at https://www.aos-rc.com/ for more details or to contact them for additional details.
For any 3d printing needed for the frame, please check out https://www.brain3d.co/ and they will help with anything you need.
The AOS 5 V2 refines and improves upon the original AOS 5 formula. A lightweight 5" frame with exceptional vibration and resonance performance and so much more.
Flight performance is the cornerstone of every AOS frame. Exceptional vibration and resonance performance reduces propwash, oscillations and motor heating. Not only does the AOS 5 V2 fly amazingly on Betaflight 4.3 stock settings it also allows you to push your PID and filter settings further than ever before to achieve unparalleled stick feel and minimal filter delay.
The new arm geometry provides even more stiffness in key directions as well as improved durability in front impact. The 3 screw motor mounting reduces weight and removes the motor hole that can be a stress riser for compressive failure.
The AOS 5 V2 offers unparalleled flexibility for your electronics supporting up to 30x30 mm stacks in the front center and rear. It also supports the DJI Air Unit and HDZero 1W VTX, the original DJI HD FPV camera or any standard micro sized camera.
The AOS 5 V2 features 2 slots for captive battery straps on the top plate as well as an XT60 pass through to keep battery cables away from the props. The GoPro mount uses the AOS standard 32x32mm mounting but includes pre installed press nuts to make mounting a breeze.
Building the frame couldn't be simpler. Just 8 standoffs and 16 screws are needed and none of the frame screws are shared with your electronics. Only 2 screws need to be undone to change an arm.



Specifications


Designed for up to 5.1 inch props (no props in view)
6 mm Arms
2mm Top Plate and Sandwich Plates
2.5mm Bottom Plate
Up to three 30.5x30.5 mm 25.5x25.5 mm or 20x20 mm stacks
32x32mm GoPro mounting holes in top plate with installed press nuts
XT60 pass through in top plate
Two captive battery strap slots
Fits the DJI Air Unit (use front stack mounting) and HDZero 1W VTX
Fits the DJI FPV camera or 19x19 mm camera
Recommended motor size 2306, 2207, 2208, 25mm
16x16 mm up to 19x19 mm motor mounting
Approx. 115g with all hardware



Packing List


1x AOS 5 V2 FPV Frame Kit
