D-LINK F3 MINI FLIGHT CONTROLLER

This is a mini version of the D-link F3 flight controller and shares many of the some components and features including a built in PDB.    However due to the smaller size this PDB only supports up to 60A, so you can only use 4 x 15A ESC with this board making it better suited to smaller micro quad copters.

FEATURES:

4oz copper & 6-layers PCB
ESC & battery solder tabs in pairs
Bigger solder pad easy to soldering
Gold-plated craft, excellent electric performance
With Betaflight SPF3 target
SPECIFICATIONS

STM F303 MCU
MPU6050 IMU
BEC: 3.3V 50mA
Working voltage: 2-6S Lipo (Max 25V)
ESC outputs: 4
Current output: 4 x 15A
Size: 27x27mm
Weight: 4.7g
Mounting: 23mm /φ2mm
