Diatone Mamba TOKA 2203.5 2200KV Racing Motor

Mamba Toka 2203.5 2200KV Racing Motor GreenMAMBA TOKA 2203.5 2200KV MotorOverall Dimension:Φ28.9×29.4mmprop mounting shaft diameter:5mmInstallation hole position:16×16mm，M3Prop: 4...
Vendor: DIATONE
Availability: In Stock
$28.95
$28.95
Subtotal: $28.95
2200KV_1_700x

Diatone Mamba TOKA 2203.5 2200KV Racing Motor

$28.95
2200KV_1_700x
23051650KV1000X1000_16_800x_ac81bb61-c1d6-492c-8b69-f58c504faff5
23051650KV1000X1000_7_800x_9e1b746c-c9f0-4cba-80c8-115420a1a722
23051650KV1000X1000_5_800x_3596ce5f-e831-4eed-9881-e123bc8abc47
3000KV_1_eb65600e-0d66-4385-9d96-4944c069cf6e_700x

Diatone Mamba TOKA 2203.5 2200KV Racing Motor

$28.95
Description

Mamba Toka 2203.5 2200KV Racing Motor Green


MAMBA TOKA 2203.5 2200KV Motor
Overall Dimension:Φ28.9×29.4mm
prop mounting shaft diameter:5mm
Installation hole position:16×16mm，M3
Prop: 4 inch
Bearing：9*4*4
Shaft Diameter:4.0mm
Lead Wire Size：24AWG×190mm
slots/poles:12N14P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：22mm
Stator Height:3.5mm
Rated Voltage:4~6S (16.8V~25.2V)
Peak Current:19.43A
ldle Current：1.0A
Maximum Power: 466.5W
Internal Resistance：160mΩ
