Diatone Toka 1404 3000 Brushless Motor

SPECIFICATION

• Overall Dimension: 20.5×15mm
• prop mounting shaft diameter:1.5mm
• Installation hole position:12×12mm，M2
• Prop: 2.5inch~4inch(Toothpick)
• Bearing： 5*2*2.5
• Shaft Diameter:2mm
• Lead Wire Size：24AWG×150mm
• slots/poles:9N12P
• Magnet Wire: 240℃ Enameled Wire
• Stator Diamter：14mm
• Stator Height:4mm
• Rated Voltage:3S~6S (12.6V~25.2V)
• Peak Current: 11.95A
• ldle Current：10V/0.3~1.0A
• Maximum Power: 286.8W
• Internal Resistance：310Ω
• Weight: 10.5g

INCLUDES

• 1 x Mamba Toka 1404 Brushless Motor
