KU:
Fi8625M
Dimensions:
40.5 × 20.5 × 36 mm
Weight:
72 g
Stall Torque :
18.5kg.cm/257.3oz.in(6V)23kg.cm/319.9oz.in(8.4V)
Control System :
Digital
Direction :
CW
Required Pulse :
500us-2500us
Bearing Type :
2BB
Gear Type :
Metal
Motor Type :
Coreless
Connector Wire Length :
30 cm
Fi8625M is FEETECH Programmable Digital Servo.
You need to use an USB interface (FE-SCPC-1) to program this servo. (For more information, please click here)
This servo is used in cars, boats, robots or where standard servos are used.
This servo can produce high-current draw from your batteries. If using NiMH or LiPo batteries, make sure they are capable of delivering approximately 2A for each servo.
Features:
Standard Size Two Ball Bearing High Torque Metal Case Programmable Digital Servo
Used 1 million times life potentiometer, high quality coreless motor.
Has the waterproof properties.
Can be programming angle of rotation to use USB interface by PC software.
Ideal for high-torque applications requiring a standard size servo
Universal connector fits Futaba, Hitec, JR, KO Propo.
One year warranty
