 Sensor Type |
Sony 1/3" CMOS Sensor |
| Scale | 4:3(default)/16:9 Switchable |
| Tv System | PAL(default)/NTSC Switchable |
| Resolution | Digital 720P/Analog 1000TVL |
| Shutter Speed | PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec |
| Video Output | 720P Digital HD/CVBS Analog Signal |
| FOV |
Digital: FOV-H:120° FOV-D: 145° Analog: FOV-H:125° FOV-D: 155° |
| Shutter Speed | Auto |
| Minimum Illumination | 0.01Lux |
| White Balance | Auto |
| DNR | 3DNR 2DNR |
| WDR | 120dB |
| Mode | DAY/CLOUDY/Night/LED |
| Fast Mode Switch | Long Press Right Button to switch among DAY/CLOUDY/Night/LED |
| Flight OSD | Cam Title / Voltage (Only in analog) / Time |
| Input Power |
Digital: 3.3V from VTx Analog: 4.5~20V |
| Language | ENGLISH/ DEUTSCH/ FRANCAIS/ PYCCKNN/ PORTUGUES/ ESPANOL/ ä¸æ–‡ |
| Working Temperature | -10°~50°C RH90% MAX |
| Working Humidity | 20~80% |
| Storage Temperature | -20°~70°C |
| Menu | Analog via camera programming board, Digital via VTx programming board |
| Consumption |
Analog:50mA±15% @ DC12V 115mA±15% @ DC5V Digital:350mA@3.3V(Powered by VTX) |
| Dimension | 14*14mm; 19*19mm(Add Bracket) |
| Weight |
4.3g(Exclude cable)
|
