Description

HummingBird F4 V2 Flight Controller ExpressLRS(ELRS)

This is a replacement Flight controller for Hummingbird F4 V2 ELRS BNF it will be compatible with the Hummingbird Mark3 VtxCamera.

Specification:

  • STM-F411 MCU for the main controller (Preloaded with Betaflight)
  • Support 1S battery ONLY
  • Current sensor onboard
  • ESC-12A Per Motor Channel BB21 MCU
  • BlHeliS Support DShot(150 300 600) Multishot
  • Gyro- BMI270
  • Onboard Sideway RGB LED controlled by Betaflight
  • Support BeeSign signal compatible with NBD VTX-Camera System
  • Onboard Diversity SPI SX1280 Receiver(EXPRESSLRS )
  • MotorPlug JST1.0
  • NBD OSD(Betaflight OSD Compatible)
  • 5V 2A Power support for external VTX Camera Or Receiver.
  • Weight: 4.27g include power cable and PH2.0 Plug, 3.45g without motor plugs/pigtails

BeeSign:
BeeSign is a protocol created by the NewBeeDrone engineering team. It is used to communicate between the flight controller and the onboard VTX OSD (NewBeeDrone Mark1,2,3 Series Video Transmitter)

Receiver Antenna: NewBeeDrone 2.4G Replacement Receiver Antennas
