Always Charge and discharge is a fireproof container and never leave unattended - this unit heats up to discharge - keep away from anything flammable
Features:
1.This lithium battery discharger made of high quality material,small size,lightweight and portable.
2.Discharges a good lithium battery to between 3.9V and 4.0V.
3.Used for long-term placement,so that the lithium battery will not break.Â
4.Efficient heat dissipation.
5.Support 3S,4S,5S,6S discharge.
Instructions:
1. First determine the battery type and number of sections, and adjust the voltage level of the corresponding discharge by pressing the button. As shown in the table below
 battery LED color
3SÂ Â Â Â Â blue
4SÂ Â Â Â Â green
5SÂ Â Â Â Â red
6SÂ Â Â Â Â Â Blue green flicker
Descriptions:
1. First determine the battery type and number of sections,and adjust the voltage level of the corresponding discharge by pressing the button.
2. As long as the LED light is on,it means the discharger is still in the discharge state. The LED light goes out and the discharge is completed.
3.Since the arrester uses the resistance heat to dissipate excess power. Therefore,there is a "221" resistor on the discharger that is hot. Do not touch it with your hands to avoid burns.
Specifications:
Battery Interface:XT60
Battery Type:Polymer Lithium Battery / Lithium Iron Phosphate Battery
Number of Battery Sections:3S - 6S
Indicator Status:LED
Size:10x8x2mm/2x0.312x0.078in
Weight:4g/0.14oz
Color:Blue And Yellow
Package Information:
Package Size:55x55x25mm/2x2.145x0.975in
Package Weight:10g/0.35oz
Polybag Package
Package Included:
1 x LIPO Suction
1Â x Heatshrink
