The Lumenier LUX F7 Ultimate Flight Controller is the next generation of the popular Lumenier LUX flight controller lineup. It uses a powerful F7 processor along with top of the line hardware. Unleash the capabilities of your FPV Racing Quadcopter with the Lumenier LUX F7 Flight Controller. The LUX F7 comes with 2 onboard gyros allowing you to choose the perfect settings for your setup. The default gyro is the tried and true MPU6000, capable of 8k/8k with high resistance to vibration noise. Alternatively enable the ICM20602 to achieve gyro refresh rates up to 32kHz.
The LUX F7 builds on all the best features of its V2 predecessor and further improves on hardware components and layout. You get a whopping 5x dedicated UART ports with built-in inversion for peripherals, along with an SD Card slot for practically unlimited data logging. Now with an integrated BetaFlight OSD, it makes it super simple to display important information on your FPV display like battery voltage, flight time, warnings, RSSI, smart audio features and more.
The features don't stop there! The LUX F7 has the ability to run 2 camera signals, with a built switching ability. This means you can run 2 cameras simultaneously and assign a switch via the PINIO feature in Betaflight to alternate between the 2 feeds at the flip of a switch.
Have you ever been in an FPV race where you need to plug in your quad, but you don't want to broadcast an FPV signal to knock your friends out of the air? Or how about you crash, and need to save your VTX from burning up while baking in the hot sun. With the LUX F7 you can remotely turn your VTX on or off via a switch on your radio! The LUX features an on-board 1A VBAT filtered power pad designed to power your VTX. Using the PINIO resource, you can assign this pad to a switch on your radio, remotely controlling the power source to your video transmitter.
Long range quad and FPV plane pilots will also love the Lumenier LUX F7. It has all the features you need to take full advantage of the long range and autonomous flight technology. The LUX F7 has an on-board barometer, buzzer pad, I2C pad, iNAV support, GPS/compass pads, and up to 8 PWM inputs S1-S8 for a ton of servo and motor control.
The Lumenier LUX F7 is a very low profile board allowing it to be mounted in a variety of ways. Signal wires can be soldered directly to the pads to save on size and weight. The LUX supports PPM or Serial RX (including FrSky, S.BUS, DSMX, etc.).Â
Lumenier™ and LUX™ are registered trademarks  of Lumenier.
