Matek H743-Wing V3 Flight Controller

Matek's H743 WING V3 Flight Controller arrives with new features and improvements over the original. This FC...
Vendor: MATEK
Availability: Out Of Stock
$175.45
$175.45
Subtotal: $175.45
333_1800x1800_503c6f83-3fac-4af5-ad48-4165c25cd501

Matek H743-Wing V3 Flight Controller

$175.45
333_1800x1800_503c6f83-3fac-4af5-ad48-4165c25cd501
22_1800x1800_239d1b9b-8f0e-4df8-8ace-7465ca66ab6f
2022-10-2414_32_55-MATEK_USD_2022_1001-1031_5_.pdf_1d004622-7ef9-4616-b911-c284ed7befad
2022-10-2414_32_41-MATEK_USD_2022_1001-1031_5_.pdf_becd1384-491e-45b8-9b0c-f3afee19f660

Matek H743-Wing V3 Flight Controller

$175.45
Description

Matek's H743 WING V3 Flight Controller arrives with new features and improvements over the original. This FC features a STM32H743VIT6 MCU running at 480MHz, dual gyros ICM42688-P(SPI1) & ICM42605(SPI4), a DPS310 (I2C2) barometer, and much more.


This version features an updated Gyro compared to the V2.


Specifications



  • Input Voltage: 3-8S LiPo
  • MCU: STM32H743VIT6
  • Gyro: ICM42688-P / ICM42605
  • OSD: Yes
  • UARTs: 8 Sets
  • ESC Connections: Yes
  • Firmware: MATEKH743
  • BEC: 3.3V, 5V, 9V, 12V
  • Current Sensor: Yes
  • Buzzer: Yes
  • Barometer: Yes
  • Black Box: Micro SD
  • Stack Size: Not Stack Mounted
  • Dimensions: 54x36x13mm
  • Weight: 30g

Includes



  • 1x Matek H743 Wing V3 Flight Controller
