Description

SCAN QR CODE FOR USER MANUAL

SPECIFICATION

  • Brand Name: NameLessRC
  • Model: AIO412
  • Item Name: F4 Flight Controller AIO OSD BEC Built-in 12A 4In1 ESC
  • Input Voltage: 2-4S Lipo /  HV Lipo
  • CPU: STM32F411CEU6 (100MHZ)
  • Sensor: MPU-6000 (connected by SPI)
  • Built-in Betaflight OSD
  • Built-in 5V 2.5A BEC Output with LC Filter
  • Built-in Current Sensor
  • Size: 28.5×28.5mm
  • Net Weight: 4.2g
  • Support DSM2/X RX, Frsky XM/XM+ RX, Frsky R9M RX , Fu-taba RX, Flysky RX, TBS Crossfire Receiver

ESC SPECIFICATION

  • Power supply: 2-4S LiPo/LiPo HV ( 7.4-17.4V)
  • Continue Current: 12A
  • Burst current: 15A
  • Firmware: BLHELI_S
  • Motor Connectors: 1.25mm header pins connector
  • Default protocol: DSHOT600

FEATURES

  • The largest support 4S Lipo HV battery, with Current meter
  • F411 Flight Controller, BEC 5V 2.5A
  • MPU6000 Gyroscope
  • Include Buzzer pad
  • Invert and non-invert SBUS port
  • Light design

PACKAGE INCLUDED

  • 1x F4 Flight Controller Built-in 12A ESC Board
  • 1x XT30 Connector Cable
  • 4x Anti-vibration Standoffs
