Package
-
1x Camera -
1x Aluminum bracket -
1x Set of screws -
1x 6pin FPV silicone cable -
1x 5D-OSD menu cable -
1x Manual
Parameters
| Model | Micro Swift 2 |
| Image Sensor | 1/3" SONY Super HAD II CCD |
| Horizontal Resolution | 600TVL |
| Lens | 2.1mm (M8) FOV160° / 2.3mm(M8) FOV 145° |
| Signal System | PAL / NTSC |
| Integrated OSD | Yes |
| One Touch Scene Setting | Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight |
| S/N Ratio | >60dB (AGC OFF) |
| Electronic Shutter Speed | PAL: 1/50~100,000; NTSC: 1/60~100,000 |
| Auto Gain Control (AGC) | Yes |
| Min. Illumination | 0.01Lux@1.2F |
| WDR | D-WDR |
| DNR | 2DNR |
| Day/Night | Color/Auto/B&W |
| Power | DC 5-36V |
| Working Current | 12V@60mA / 5V@130mA |
| Net Weight | 5.6g |
| Dimensions | 19mm*19mm*19mm |
Download
User Manual
