Do you want to become a WORLD CHAMPION like MCK?
Except hard-working, a good camera is also the important key,
as the camera is just like the eyes of pilots.
Except hard-working, a good camera is also the important key,
as the camera is just like the eyes of pilots.
Dimensions
Package
-
1x Camera -
1x 1928 ABS bracket -
1x 6pin FPV silicone cable -
1x Set of screws -
1x Manual
Parameters
| Model | Runcam Racer MCK Edition | |
| Image Sensor | Super WDR CMOS Sensor | |
| Horizontal Resolution | 1000TVL | |
| Lens |
|
|
| Screen Format | 4:3 / Widescreen Switchable | |
| Signal System | NTSC / PAL Switchable | |
| Mirror/Flip | Available | |
| Integrated OSD | Yes | |
| One Touch Scene Setting | Personal / Lightrax | |
| S/N Ratio | > 50dB | |
| Electronic Shutter Speed | Auto | |
| Min. Illumination | 0.01Lux@1.2F | |
| WDR | Super WDR | |
| Day/Night | Auto | |
| Menu Control | Joystick Control / UART Control Switchable | |
| Power | DC 5-36V | |
| Current | 110mA @ 5V / 40mA @ 12V | |
| Housing Material | ABS | |
| Net Weight | 5.5g | |
| Dimensions | L19mm*W19mm*H18mm |
