Power |
|
| Power supply AC: | 110-230V ±10%, 50/60Hz |
| Power supply DC: | 12V, 24 – 60V |
| Maximum load: | Standard version – 16A / UL version – 15A |
| Device power consumption: | < 1 W |
Special functions |
|
| Dry contacts: | Yes |
| Roller shutter mode: | No |
| Device temperature protection: | No |
| Overload protection: | No |
| Power measurement: | No |
| Working without a neutral wire: | No |
Features |
|
| Control channels: | 1 On/Off Relay Channel |
| Operational temperature: | 0°C to + 40°C |
| Intelligent On/Off: | Yes |
| Local and smart control: | Yes |
| Sunrise/Sunset timer: | Yes |
| Built-in weekly scheduler: | Yes |
Connectivity |
|
| Wi-Fi protocol: | 802.11 b/g/n |
| Radio frequency: | 2400 – 2500 MHz |
| Radio signal power: | 1mW |
| Wireless range: | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
Dimensions |
|
| Size: | 41mm x 36mm x 17mm |
