Spedix GS40F 4in1 mini esc 20x20 6S F3

Overview:

GS40F 4IN1 MINI is an extremely reliable 20*20mm mount 6S 4IN1 ESC.
Limited by the smaller size of 20*20mm ESC, Engineers have always been using 3mm mini MOSFET used on 20*20mm ESCs.  This compromise made these ESCs vulnerable to the ever-growing demand of heat sinking capabilities and current/voltage tolerance of the FPV market.
With our innovative design, by separating the control board and the power board, we successfully implemented full-size 5*6mm MOSFET onto this 20*20mm ESC.  By combining reliable hardware with the fastest GD32F3 MCU in the market,

We are able to present you with a high performance mini 20*20mm ESC of extreme reliability and responsiveness.

Features:

1.Innovative double deck design enables the implementation of full-size 5*6 MOSFET on 20*20mm mini 4IN1 ESC.

2. 40V MOSFET improves the overall reliability in fast response to throttle signals，making the 6 cell input capable in the real world

3. GD32F3 MCU provides highest responsiveness in the market.

4.Extremely small size makes mounting on smaller frames easier than ever.

Specifications

Brand: Spedix

Model: GS40F Mini 4 IN 1

Input:3-6 Cell LiPo

Continuous Current: 40A

Burst Current: 50A≤10S

BEC: No

Current Detection: YES

Firmware: BLHeli_32

Dimensions: 40x31x8mm

Mount Holes: 20x20mm

Weight：13.2g

Application: 200-300mm racing drone

Perfect as a combo with the BrainFPV Radix LI or any other 20x20 or full-sized flight controller.
