Aerospace-grade Aluminum Front Plate
The aviation-grade aluminum headpiece provides excellent protection for the lens, and it is embedded with custom silicone damping material, resulting in effective anti-vibration performance for the lens. The GyroFlow effect is enhanced for better stability.
Open-source 3D printing schematics are available, enabling you to print them with different thicknesses to accommodate various lens installations.
100% efficient heat dissipation
We have found that the O3 video transmitter shuts down due to high CPU temperatures during prolonged high-temperature operation. To address this issue, we have specially designed a 7075-T aerospace-grade aluminum component for the O3 video transmitter, doubling its heat dissipation efficiency! Additionally, it features 20x20 mounting screw holes, making it compatible with Link, TX800, and other 20-hole video transmitters.
Note: The test data is conducted at an ambient temperature of 26 degrees Celsius. The actual performance may vary depending on the temperature of the usage environment.
Custom-made aerospace-grade aluminum components.
Specially designed to solve the TF card insertion issue of O3 without disassembly. Easily insert the card without any hassle. It also features a dedicated frequency position for O3 and Link video transmitters, making it super convenient for Type-C connection!
Note: BEE35 comes with a carbon
fiber bottom plate. BEE35 PRO comes
with an aluminum alloy heat sink bottom plate.
fiber bottom plate. BEE35 PRO comes
with an aluminum alloy heat sink bottom plate.
H-FOV135°
135° wide-angle without dark corners.
Two battery installation methods.
Super convenient battery strap design allows for horizontal or vertical battery mounting.
Super durable injection-molded ring.
Made of high-strength imported composite material with built-in LED strip mounting groove.
Compatible with flight towers.
Supports installation of various flight towers and AIO (All-In-One) boards in sizes of 20x20, 25.5x25.5 (45° 90°), and 30.5x30.5.
20-hole MINI flight tower —— Recommended (Perfect fit)
25.5-hole AIO flight controller —— Recommended (Perfect fit)
30.5-hole standard flight tower —— Not recommended
(Installation is compact and requires some hands-on skills)
25.5-hole AIO flight controller —— Recommended (Perfect fit)
30.5-hole standard flight tower —— Not recommended
(Installation is compact and requires some hands-on skills)
Compatible with video transmitters.
The standard version supports various HD and analog video transmitter installations in 2020 | 25.525.5 (45° 90°) formats.
For installing LINK or O3 video transmitters, it is recommended to use an all-in-one (aio) flight controller. If you plan to install a flight stack, it is advisable to use the pro version.
Note: BEE35 comes with a carbon fiber bottom plate. BEE35 PRO comes with an aluminum alloy heat sink bottom plate.
Multi-function antenna mount.
Type-C adapter cable directly plugs into the flight controller without disassembling the aircraft.
Quick Release Solution
Only 6 screws are to be removed for freeing drone body and propeller guard.
Detachable damping gimbal, Convenient for mounting different cameras with damping.
Specifications
| Product Name | SpeedyBee Bee35 Frame |
| Wheelbase | 153mm |
| Top Plate Thickness | 3.5mm |
| Bottom Plate Thickness | 2mm |
| Camera Mounting Distance | 19/20mm |
| ESC/Motor Mounting Height | 24mm |
| Flight Stack Mounting Holes | 20*20/25.5*25.5/30.5*30.5mm |
| Video Transmitter Mounting Holes | 20*20/25.5*25.5 |
| Propeller Size | 90mm |
| Motor Mounting Holes | 12*12mm |
| Weight | 138g |
| CNC Heat Sink | 15g |
| Camera Gimbal | 28g |
| Recommended Motor | 1806/2004/2006 |
| Recommended KV | 4S/2500-3500KV,6S/1800-2300KV |
| Recommended Battery | 900-1500mAh 4S/6S |
