The ZOHD Orbit wing comes in a variety of configurations
- Kit - you provide all the electronics, power train and servos.
- PNP - all electronics, servo and motor included - (receiver required to match your radio - not included)
PNP Kit also included a flight stabilization controller that also has a launch mode that keeps it stabilized while in a climb
This wing has a unique design where the servos are inside the main body and control the ailerons via a rod through to the wing making the wings detachable for transport without any plugs needing to be detached. Also helps in a crash.
Also note the redesigned plastic protection on the bottom to help protect your craft
.jpg)
Kit
| General |
Brand Name: ZOHD Item Name: Orbit Wing Wingspan: 900mm/35.43in Length: 422mm/16.61in Recommended Parts: (Not Included) Motor: 2204 1870KV or similar Motor Shaft Diameter: 5mm ESC: 30A W/1A BEC(XT60 connector) Servos: 2pcs 8g digital servo Propeller: 6x3 Recommended Battery: 3S 1300-2200mAh 25C XT60 Plug - (Can also fit a 4s 1500) Recommend Radio: ≥6CH |
| Package Contents | 1 x ZOHD Orbit RC Airplane KIT |
PNP
| General |
Brand Name: ZOHD Item Name: Orbit Wing Wingspan: 900mm/35.43in Length: 422mm/16.61in Flying Weight: 455g(w/o FPV gear) Material: Crash Resistable EPP CG: 11.50cm from the wing leading edge(a bump CG mark under the wing) Color: White + Black Motor: ZOHD 2204 1870KV BL Motor Shaft Diameter: 5mm ESC: 30A W/1A BEC(XT60 connector) Servos: 2pcs 8g digital servo Propeller: 6x3 Recommended Battery: 3S 1300-2200mAh 25C XT60 Plug Recommend Radio: ≥6CH Flying speed: 10 to 85km/h |
| Package Contents | 1 x ZOHD Orbit RC Airplane PNP |
